- Standard Trench ShieldLightweight Shields. Heavy-Duty Protection Guardian aluminium trench shields are designed for New Zealand ground conditions and the realities of civil sites. We help you choose the right setup so your crew can work safely and stay compliant. Protection in Action Suitable for Small 1.6 Tonne Machines Designed to be as light as possible while having maximum strength, so you can use a small 2-tonne or even a 1.6-tonne digger. This results in less cost for machine hire, fuel, and running costs. Ideal for small to medium projects and one of the most widely used shields on New Zealand civil sites. Stackable for Versatility The stackable feature enables customisation of trench depth from 1.2m up to 3.6m (when stacked 3 shields high) in stable soil conditions. This adaptability is particularly useful in projects with varying excavation requirements. Inbuilt Lifting Points for Safety Equipped with inbuilt lifting points, ensuring secure handling during installation and removal. This design minimises the risk of accidents, promoting a safer work environment. Customisable This small trench shield can be configured into 5+ different set-ups depending on your trench protection needs, making it a very versatile option for a small to medium urban site. The struts width is…
- Large Trench ShieldLightweight Shields. Robust Protection Our large trench shields are engineered to offer substantial length without excessive weight, making them easier to transport, install and reposition on site. Protection in Action Lightweight Design Constructed from high-grade aluminium, these shield is lighter than traditional steel options, facilitating easier transport and assembly. This is especially important for projects with weight restrictions, allowing smaller, more cost-effective machines to move the shields, reducing fuel and machine hire costs. High Load Rating These shields are designed to be lightweight while maintaining a higher kPa rating than many shields of similar size. They provide robust protection against soil pressure, helping protect workers in the trench in different soil conditions and keeping your site compliant. Extended Length Ideal for longer trenching projects, reducing the need for frequent repositioning and helping crews work faster while maintaining continuous trench protection. Adjustable Strut Sizes Offers versatility to match different trench widths, allowing you to save money by using the same shield in multiple different-width trenches. Under Strut Clearance Facilitates unobstructed access for personnel and equipment like pipes, streamlining operations within the trench and allowing you to lay different diameter pipes while also protecting your team. Standard strut clearance is 1.3m and…
- Manhole BoxesRapid Delivery. Easy Setup. Maximum Safety. Aluminium manhole boxes for access chambers, utility holes, and shafts. Simple design, easy to use, certified to meet safety standards. Protection in Action Compact & Lightweight On a residential street with limited access, a crew can position the box using a smaller excavator—no need for heavy, large gear that creates delays because of limited space. Quick Assembly Two people and a digger operator can assemble and position the box in under 10 minutes. Quick and easy to keep tight projects on schedule. Available in Three Sizes for the Right Fit Choose from our range: 2.0m, 2.4m or 3.0m options. The option of using fixed or adjustable struts (ranging from 0.8m to 2.4m) allows you to tailor the box to different trench widths and project requirements, while still having the under-strut clearance for a pipe to pass through the shield. Stackable for Deeper Excavations All sizes can be safely stacked up to three boxes high as long as the ground kPa rating doesn’t exceed the box’s rating for deeper trenches. This provides extended protection without the need for additional systems. In multi-stage infrastructure projects, units can be stacked as the trench deepens, maintaining safety standards…
- Modular Shields/BoxesModular trench shoring systems Aluminium modular shoring systems offering exceptional versatility. Configure as trench shields, 3-sided boxes, or complete closed boxes depending on excavation requirements. Ideal for working around services or creating custom configurations for irregular excavations. Protection in Action Core features: Tongue and groove panels align for smooth one-piece appearance Lightweight panels for easy transport and handling (can fit on ute or small trailer) Quick assembly using gravity-activated pins (no R-clips needed) Wall thickness 50mm (minimises excavation, backfilling, and restoration costs) 600mm legs available to hold shield off ground for pipes/cables Adjustable struts accommodate varying trench widths Stackable to a maximum of 9m for the 1.5m modular panels and to 3m for the 3m modular panels. 5 Examples of the many different Modular Shield Configurations Our Range Product Code Panel Length Panel Height Weight Per Panel kPa Rating Panel Thickness 2411 1.5m 600mm 34kg 74kPa 50mm 2412 1.8m 600mm 39kg 57kPa 50mm 2413 2.4m 600mm 52kg 44kPa 50mm 2414 3.0m 600mm 64kg 26kPa 50mm Applications Complex excavations requiring custom configurations, working around multiple services, heavy-duty retaining walls, open pits, situations requiring 3 or 4-sided protection, sites needing minimal excavation width. Product Videos Learn how to make the guardian modular…
- Trench Soldier SetsManual Soldiers Ideal for Confined Spaces This lightweight manual soldier is specifically designed for small contractors, such as drain layers, who may not always have access to heavy machinery on-site. Weighing only 38kg per 2.4m set including struts, its manageable size allows for easy handling without the need for a digger, making it ideal for confined spaces and quick setups. Compact Dimensions With dimensions of 0.2m in width and ranging from 1.8m to 3.0m in height, these soldiers are well-suited for deployment in narrow trenches, maximising safety while minimising spatial footprint. Safety Compliance Rated for depths up to 3.0m and a pressure rating of 20 kPa, it meets stringent safety standards, helping crews work with confidence on site. Adjustable Strut Sizes The adjustable strut sizes from 0.4 to 2.4m, with over 4 different strut options. This flexibility allows customisation based on specific trench requirements, enhancing versatility on various projects. Manual Soldier Range Product Code Panel Width Panel Height Weight Per Set Panel Thickness 2451 0.2m 1.8m 35kg 45mm 2452 0.2m 2.4m 38kg 45mm 2453 0.2m 3m 49kg 45mm The increase in weight for the 3.0m soldiers is due to the requirement for three struts, whereas the other two sizes only…
- Grave ShoringCore features: Lightweight aluminium trench shields for easy handling and installation Stackable panels to suit varying grave depths Purpose-designed struts allow unobstructed lowering of coffin or casket Green powder-coated finish to create a natural, respectful appearance Compatible with artificial grass mats and cemetery surrounds Easy to clean and maintain between uses Our Range Product Code Panel Length Panel Height Weight Per Panel kPa Rating Panel Thickness Cutting edge 2470 2.4 0.6 40 30 0.45M Yes 2471 2.4 0.8 50 30 0.45M No 2471 has no cutting edge so it can be used as a topper or as bottom if cutting edge is not required. Applications Cemetery and burial excavations, grave digging in disturbed ground, sites where worker safety and public safety are critical, services requiring a professional and dignified graveside presentation. Protection in Action Become a Trench Shield Expert Answering All Your Questions About Our Grave Shoring Certified to International Standards The Lite Guard cemetery shield meets the safety requirements of AS 4744.1-2000 (Australian Standard), BSEN 1331.142 (British European Standard) and 29CFR Part 1926 OSHA Sup Part P (USA Standard) Standard Grave Shoring Accessories Product Image Product Code Description Dimension 2479 End Closure Panel 2400 (H) x 300 (W) mm…
- Trench Safety AccessoriesLadder Platforms & Ladders Safe, stable access in and out of trenches is critical on active sites. Guardian ladder platforms, extension ladders and crossover walkways are designed to provide secure entry, exit and over-trench access, reducing the risk of slips and falls. Lightweight construction and non-slip surfaces allow for fast installation while maintaining strong, reliable performance in demanding conditions. Our Range Protection in Action Davit Arms & Winches Guardian davit arms and winches provide a compliant solution for fall arrest, rescue and controlled lifting in trench and confined space environments. Designed for fast setup on site, these systems allow safe lowering and recovery of personnel, as well as controlled lifting of materials. Corrosion-resistant construction and adjustable configurations make them suitable for repeated use across multiple sites. Our Range Protection in Action Handrails Guardian handrail systems create a clear physical barrier around open trenches, improving edge protection and site safety. Built from lightweight yet robust materials, the handrails attach directly to trench shields for fast installation. Multiple length options allow handrails to be configured to suit different trench sizes while meeting site safety requirements. Our Range Product Code Dimensions Material Description 2485-2 2.0m Aluminium Handrail set 2 x Feet To Suit…
-
-
- About Us
- Knowledge Hub
- Contact Us
Need More Information?
Whether you need a quick answer or want to discuss your fleet requirements, we're here to help.
Yard broom with white poly bristles & steel bracket
